Next-level detection, unparalleled protection
The H9c is equipped with dual-lens, co-enabled detection technology to safeguard even the most complex environments in a way that is tailored to your needs. You can use these advanced features at any time without committing to a subscription plan.- AI-Powered Human / Vehicle Shape Detection (Available on Both Lenses)
- PT Lens Auto-Tracking (On Human Movements)
- Co-Detection for Interlinked Lens Auto-Actions
- Adjustable Detection Sensitivity
- No Subscription Required
Specifications
Model
CS-H9c-R100-8H33WKFL
Image Sensor
1/2.7″ Progressive Scan CMOS
Shutter Speed
Self-adaptive shutter
Lens
Upper Camera: 2.8mm@ F1.6, viewing angle: Diagonal 130°, Horizontal 108°, Vertical 56° Bottom Camera: 6mm@F1.6, viewing angle: Diagonal 62°, Horizontal 55°, Vertical 28°
PT Angle
Pan: 350°, Tilt: 80°
Minimum Illumination
0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)
Lens Mount
0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)
Lens Mount
M12
Day & Night
IR-cut filter with auto-switching
DNR
3D DNR
WDR
Digital WDR
Black & White Night
30m / 98ft
Max Resolution
2304 × 1296
Frame Rate
Max:15fps; Self-Adaptive during network transmission
Video Compression
H.265 / H.264
H.265 Type
Main Profile
Video Bit Rate
Quad HD, Full HD, Hi Def, Standard. Adaptive bit rate.
Audio Bit Rate
Self-Adaptive
Wi-Fi Standard
IEEE802.11b, 802.11g, 802.11n
Frequency Range
2.4 GHz ~ 2.4835 GHz
Channel Bandwidth
Supports 20MHz
Transmission Rate
11b 11 Mbps, 11g 54 Mbps, 11n: 150 Mbps
Wi-Fi Pairing
AP paring
Protocol
EZVIZ cloud proprietary protocol
Interface Protocol
EZVIZ cloud proprietary protocol
Wired Network
RJ45 × 1 (10M / 100M Adaptive Ethernet Port)
Security
WPA-PSK/WPA2-PSK
Smart Alarm
AI-Powered Human Shape Detection / AI-Powered Vehicle Shape Detection / Motion Detection
Auto Tracking
Supports
Customized Alert Area
Supports
Two-way Talk
Supports
Preset Locations
Supports
General Function
Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark
Operating Conditions
-30°C to 50°C ( -22 °F to 122 °F ) Humidity 95% or less (non-condensing)
IP Grade
Weatherproof Design
Power Supply
DC 12V/1.5A
Power Consumption
MAX. 12W
Dimensions
145 × 116 × 142mm (5.71 × 4.57 × 5.59 inch
Packaging Dimensions
150 × 150 × 194mm (5.90 × 5.90 × 7.64 inch)
Weight
Net Weight: 668 g
With Package: 960 g
In the box
– H9c Camera
– Drill Template
– Screw Kit
– Waterproof Kit
– Power Adapter
– Regulatory Information
– Quick Start Guide
Certifications
CE / WEEE / RoHS / REACH
